Minimum Selection Requirement to complete the configuration:

• Input Type
• One Output Panel



Following functions are included by default (cannot be modified in the online configurator)

• 19” 3 U aluminum subrack
• Main switch
• Mains fuses
• Circuit breaker panel
• Emergency stop system
• Status LEDs for phase presence and emergency stop
• ON/OFF switch for switched outputs



Possible configuration

Power Input

• Mains Input: 400 V 3-phase or 230 V 1-phase
• Preferred connector types: e.g. IEC 60309 3L+N+PE, 6h, IEC 60320-C20, Harting Han 3A with Han Q 5/0
• With or without EMC filter

Power Output

• AC Outputs: 2 rear panels with different connector types such as IEC 60320-C13, IEC 60320-C19 or CEE 7/3 Type F (Schuko).
• DC Output: 24 V DC, 14.6 A power supply with rear output panel
• Permanent AC Service Outputs: IEC 60320-C13 or CEE 7/3 Type F (Schuko) at the front and/or rear panel

Features:

• RCD circuit breaker
• Transparent cover for the circuit breakers
• Surge Arrester
• Inrush Current Limiter

Additional Information:

• On customer request the safety features and power distribution can be divided into two devices. Please state requirement in additional comments.
• Optional remote management module (on/off function, all states can be queried remotely and all switching functions can be performed remotely) on custom request. Please state requirement in additional comments.
• All outputs except the "Service" outputs will be switched off by the Emergency Stop system
• All AC outputs are protected by circuit breakers.
• For IEC 60309 connectors EMC input filter can be selected. If EMC filter is required with other mains input connector, please state in additional requirements field

For more information about the installation and safety system, please download the user manual.



Please download our Standard Color Pattern Guide for information about our standard color offering.
